    3 OTDR LOT2100 MINI Fiber Tester Equipment for FTTx Maintenance and Troubleshooting

    Ask Lasest Price
    Model Number : LOT2100 series
    Brand Name : LinkU
    Supply Ability : 500 Unit/Units per Month
    Price : $260.00 - $640.00/units
    • Product Details
    • Company Profile

    3 OTDR LOT2100 MINI Fiber Tester Equipment for FTTx Maintenance and Troubleshooting

    Products Description
    Description: The LOT2100 OTDR is a highly cost-effective, easy-to-use diagnostic tool, specially designed for FTTH network construction and maintenance. Its user-friendly interface has been designed for simple, one-button testing.

    Features: ❖ Handheld & lightweight (0.3 Kg)
    ❖ Build-in OLS/OPM/VFL modules
    ❖ 1000 groups of test records storage
    ❖ Event Map
    ❖ 3.2-inch LCD screen
    ❖ Professional PC software for generating test report
    ❖ One-button automatic test
    Product Paramenters
    Model
    LOT2100
    LOT2100-15F
    LOT2100-16F
    Wavelength (±20nm)
    1310/1550
    1550 with filter
    1625 with filter
    Dynamic Range (dB) (1)
    22/20
    20
    20
    (1) Dynamic range is measured with maximum pulse width, averaging time is 3 minutes, SNR=1; The level difference between the RMS noise level and the level where near end back-scattering occurs.


    SC/PC connector, USB cable, AC power adapter, analysis software(CD), certificate of calibration, user’s guide (CD), carrying bag
    5ns/10ns/25ns/50ns/100ns/250ns/500ns/1μs/2.5μs/5us/10μs/20μs
    Distance Accuracy
    ± (1m + measuring distance × 5×10-5+ sampling resolution)
    Attenuation Accuracy
    ±0.05 dB/ dB
    Reflectance Accuracy
    ±4 dB
    Event Dead Zone (EDZ) (2)
    3m
    Attenuation Dead Zone (ADZ) (2)
    8m
    OLS Module
    -5dBm
    OPM Module
    850/1300/1310/1490/1550/1625nm , +26~-50dBm
    VFL Module
    1 mW @ 650nm
    Data Storage
    1000 records
    Connectivity
    USB
    Power Supply
    Li-ion Rechargeable Battery/ AC Adapter
    Battery Life
    10 hours / 20 hours (standby)
    Operating Temperature
    0℃ ~ 50℃
    Storage Temperature
    -20℃ ~ 70℃
    Dimensions (L*W*H)
    170mm*82mm*35mm
    Standard Accessories:
    SC/PC connector, USB cable, AC power adapter, analysis software(CD), certificate of calibration, user’s guide (CD), carrying bag
    (2) Event Dead Zone and Attenuation Dead Zone are measured with minimum pulse width;


    If you have special needs of customized products, please contact us.
